Deep learning miniature bearing product characteristics
by：Waxing
2020-11-20
Deep learning miniature bearing product features metric series miniature ball bearings, 1 -
9 mm, with guard stop bearing, 1 -
9mm。
Inch series, 1.
016 -
9.
525 mm, inch series belt guard stop miniature bearing, 1.
191 -
9.
525mm。
NSK brand 68,69,60,62,63 supplies series and F6 carry penal miniature bearing.
Miniature bearing brand R (
Thick type)
,L（
Thin)
,A（
Very thin)
,RF（
Thick flange type)
,LF（
Thin flange type)
,AF（
A very thin flange type)
，NR（
Outer ring with stop ring type)
Metric size of miniature bearing, and RI, RIF (
Flanged)
Inch size series of miniature bearing.
Miniature bearing features: 1.
Sealing form: open, Z, ZZ, RS, 2 RS, 2 rz 2.
Level of accuracy: ABEC -
1,ABEC-
3,ABEC-
5,ABEC-
7. 3.
Level of vibration: V1, V2, V3 and V4 4.
The noise level: Z1, Z2, Z3 and Z4 of 5.
Internal clearance code: C0, C2, C3, C4 and C5 6.
Stainless steel material: stainless steel (
AISI440C、AISI304 AISI316)
7, ceramics.
Retainer: stainless steel, PTFE, nylon 8.
Bearing ring and ball hardness: 59 -
63 HRC explanation: 1.
Z is on behalf of the miniature bearing of single metal dust cover, ZZ represent both sides have metal dust cover RS on behalf of miniature bearing are single-sided contact rubber seal, 2 RS on behalf of the both sides have a non-contact rubber seal RZ represents miniature bearing of single contact type rubber sealing ring, 2 RZ on behalf of the two sides have contact rubber seal
