Teach you how to install the taper roller bearing with water pump shaft bearing

Teach you how to install a tapered roller bearing with water pump shaft bearing, bearing installation: the installation of the bearings must be conducted in a dry, clean environment conditions. Before installation should carefully check the shaft and the shell surface, convex shoulder of end face and groove and the connection surface machining quality. All matching connection surface must be carefully cleaned and remove burrs, rough surface must remove all sand castings. Bearing should be taken before installation with petrol or kerosene wash clean, dry after use, and to ensure good lubrication, grease lubrication, commonly used bearing lubrication may be adopted. Using grease lubrication, should choose without impurities, antioxidant, antirust, superior performance, such as extreme pressure grease. Grease filling quantity for bearings and bearing box - 30% of the volume 60%, unfavorable and overmuch. With sealing structure of double row tapered roller bearing and water pump shaft bearing has good filling grease, users can directly use, shall not be clean. Bearing installation, it must be in the ring width on the circumference of a circle of equal pressure, to press the ring into, can not use ð ¨ +  top tools directly on bearing face, in order to avoid damage In the case of a small amount of interference, but at room temperature with the sleeve pin bearing ring end face, with a ð ¨ +  head banging on sleeve, through the sleeve ring is balanced If large quantities of installation, can use hydraulic press. Fashionable, should guarantee the outer end face and the shell shoulder end face, inner ring end face and the shaft shoulder end face pressure, there is no gap. When large amounts of interference, can use oil bath heating or sensor heating method to install the bearing, the heating temperature range of 80 ℃ - More than 120 ℃, 100 ℃, the highest can't. At the same time, nut or other appropriate method is applied to tighten the bearing, in order to prevent the bearing width after cooling contraction and make the clearance between the ring and the shaft shoulder. Single row tapered roller bearing installed last should undertake clearance adjustment. Clearance value should be used according to different conditions and cooperate with the amount of interference and specify the size. When necessary, shall be tested to determine. Double row tapered roller bearing and water pump shaft bearing in have been adjusted when delivery from factory clearance, installation time don't have to adjust. Bearing installation should rotate after the test, first of all to the axis of rotation or bearing box, without exception, with a power of no load, low speed, then according to the condition of operation gradually increase the speed and load, and detection noise, vibration and temperature rise, found abnormal, should stop and check. Running test normal rear deliverables. A: what are the cause of the water pump bearing heating, you know what the next: water pump bearing factory tutor you how to determine axial clearance of the bearing relevant tags: auto water pump bearing, shaft bearings, water pump bearings, auto water pump bearing related news which cases will fever auto water pump bearing thermal and bearing performance of engine cooling system of key parts of automotive water pump bearing water pump bearing why use general auto water pump bearing grease appears channeling dynamic circumstance how to deal with related products
