Spherical Thrust roller bearing
Spherical Roller Thrust Bearings
Spherical roller thrust bearings also called spherical thrust roller bearings have specially designed raceways and barrel-shaped rollers (convex rollers). The raceway of housing washer of this bearing type is spherical with the center of the radius located on the bearing axis. Spherical roller thrust bearings are separable design, making it possible to mount and dismount the housing washer separately from the shaft washer and roller and cage assembly, as well as maintenance inspections. The design provides self- alignment capability to the bearing, some shaft misalignment can be tolerated. The contact angle is approximately 45° enabling the bearing to support high axial load and radial load up to 55% of axial load. They are suitable for relatively high speeds. The bearings have pressed steel cages or machined brass cages. Because of the large load capacity and self-aligning characteristics, Spherical roller thrust bearing is often used for injection molding machines, crane hooks and other large machines.
Size range: 60 mm to 710 mm I.D
PRODUCT FEATURES
Unlike other thrust bearings in the sample, these bearings have a very high axial load capacity and can withstand several radial loads while being subjected to axial loads, but the radial loads must not exceed 55% of the axial load.
As long as the loads P and P0 do not exceed 0.05C0 and the shaft rotates, the bearings allow the centering angles listed in the table below.
Bearing Diameter Series Self-aligning Angle Bearing Diameter Series Self-aligning Angle 200 Series 1°~1.5°300 Series 1.5°~2°400 Series 2°~3° Small values are suitable for larger bearings, and are allowed when the load is increased. The centering angle will decrease.
Oil lubrication is generally used when in use.
Thrust tapered roller bearings can only bear one-way axial load and can limit the axial displacement of the bearing in one direction, so it can be used as one-way axial positioning. Compared with the thrust cylindrical roller bearing, the bearing capacity is large, the relative sliding is small, but the limit rotation speed is low.
Product information | |||
Style Name | 29326 Spherical Thrust Roller Bearing | Weight | 8.17KG |
Size | 130*225*58mm | Material | Gcr15 Bearing steel |
MOQ | 10PCS | Seals Type | |
Precision | P4 P5 P6 | Cage | Copper |
Service | OEM,ODM Or Customized | Production Time | 30-45 days after samples approved and deposit received. |
FOB Port | QINGDAO | Payment Term | T/T, L/C at sight |
Feature | In this type of bearing, the spherical roller is arranged obliquely. Since the raceway surface of the raceway is spherical and has a self-aligning property, the shaft can be allowed to have some inclination | ||
The axial load capacity is very large, and it can withstand several radial loads while being subjected to axial load | |||
Generally used for oil lubrication | |||
Applications | Hydroelectric generators, vertical motors, propeller shafts for ships, reducers for rolling mill rolling screws, tower cranes, coal mills, extruders, forming machines | ||
