Bearing 32052 tapered roller bearing 32052 bearing
Product | Taper Roller Bearing |
Model Number | 32052 |
Bore Size(d) | 26mm |
Outside Diameter(D) | 400mm |
Width | 87mm |
Bearing Brand | WXING |
Cage | Steel Cage |
Material | Chrome Steel |
Sampe & Stock | Available, in stock |
Character | High precision,Long working life |
Port of Shippment | Qingdao, Tianjin, Shanghai, Guangzhou |
Shipping | by Sea, by Air, by express/courier |
cone structure bearing taper roller baring 22 series models
| Model No | Size(mm) | Weight (kg) | Model No | Size(mm) | Weight (kg) |
| 32203 | 17*40*17.25 | 0.18 | 32219 | 95*170*45.5 | 3.43 |
| 32204 | 20*47*19.25 | 0.158 | 32220 | 100*180*49 | 5.31 |
| 32205 | 25*52*19.25 | 0.199 | 32221 | 105*190*53 | 6.34 |
| 32206 | 30*62*21.25 | 0.356 | 32222 | 110*200*56 | 7.62 |
| 32207 | 35*72*24.25 | 0.426 | 32224 | 120*215*61.5 | 9.6 |
| 32208 | 40*80*24.75 | 0.561 | 32226 | 130*230*67.75 | 11.8 |
| 32209 | 45*85*24.75 | 0.567 | 32228 | 140*250*71.75 | 14.7 |
| 32210 | 50*90*24.75 | 0.645 | 32230 | 150*270*77 | 8.4 |
| 32211 | 55*100*26.75 | 0.93 | 32232 | 160*290*84 | 23.3 |
| 32212 | 60*110*29.75 | 1.26 | 32234 | 170*310*91 | 32.3 |
| 32213 | 65*120*32.75 | 1.28 | 32236 | 180*320*91 | 27.9 |
| 32214 | 70*125*33.25 | 1.66 | 32238 | 190*340*97 | 36.1 |
| 32215 | 75*130*33.25 | 1.76 | 32240 | 200*360*104 | 43.6 |
| 32216 | 80*140*35.25 | 2.19 | 32244 | 220*400*114 | 62.7 |
| 32217 | 85*150*38.5 | 2.7 | 32248 | 240*440*127 | 81.3 |
| 32218 | 90*160*42.5 | 3.61 | 32252 | 260*480*137 | 100.2 |
Product name | NSK 32052 taper roller bearing |
Material | Chrome Steel GCr15 |
Inner Diameter | 260mm |
Outer Diameter | 400mm |
Dimension | 87.7mm |
Weight | 1.6kg/pc |
Ball Bearings Feature | 1 Long life span 2 High rotating speed&Low noise |
Bearing Package | Pallet,wooden case,commercial packaging or as customers' requirement. |
Service | OEM service provided |
Delivery time | 3-10 days depends on quantity needed |
| 30300 series | ||||
| Model | d mm | D mm | H mm | W kg |
| 30302 | 15 | 42 | 14.5 | 0.093 |
| 30303 | 17 | 47 | 15.5 | 0.13 |
| 30304 | 20 | 52 | 16.5 | 0.165 |
| 30305 | 25 | 62 | 18.5 | 0.263 |
| 30306 | 30 | 72 | 21 | 0.387 |
| 30307 | 35 | 80 | 23 | 0.515 |
| 30308 | 40 | 90 | 25.5 | 0.747 |
| 30309 | 45 | 100 | 27.5 | 0.984 |
| 30310 | 50 | 110 | 29.5 | 1.28 |
| 30311 | 55 | 120 | 32 | 1.63 |
| 30312 | 60 | 130 | 34 | 1.99 |
| 30313 | 65 | 140 | 36.5 | 2.44 |
| 30314 | 70 | 150 | 38.5 | 2.98 |
| 30315 | 75 | 160 | 40.5 | 3.57 |
| 30316 | 80 | 170 | 43 | 4.27 |
| 30317 | 85 | 180 | 45 | 4.95 |
| 30318 | 90 | 190 | 47 | 5.8 |
| 30319 | 95 | 200 | 50 | 6.8 |
| 30320 | 100 | 215 | 52 | 8.22 |
